Professionelles zylinderförmiges doppeltes Reihen-Rollenlager NN3020K/W33 mit Nylonkäfig
|
Modellnummer |
Rollenlager NN3020K/W33 |
|
Struktur |
Rollenlager |
|
Art |
Rollenlager |
|
Material |
Chromstahl, Edelstahl, Kohlenstoffstahl |
|
Käfig |
Messingkäfig, Stahlkäfig |
|
Maß |
100mm×150mm×37mm |
|
Gewicht |
2.26kg |
|
Präzision |
P0=ABEC-1, P2=ABEC-9, P4=ABEC-7, P5=ABEC-5, P6=ABEC-3 |
|
Freigabe |
C0, C1, C2, C3, C4 |
|
Geräuschpegel |
EMQ V1 Z2, EMQ V2 Z3, EMQ V3 Z4, EMQ V4 |
|
Toleranz |
ABEC-1, ABEC-3, ABEC-5 |
|
Härte |
HRC60-63 |
|
Grundlegende Laden-Bewertung (kN) |
Dynamisch (Cr): -- |
|
Static (Herz): -- |
|
|
Maximuum-Samen |
Fett (r/min): -- |
|
Öl (r/min): -- |
|
|
Bescheinigungen |
ISO-9001:2008 |
| d (Millimeter) | D (Millimeter) | B (Millimeter) | Masse (Kilogramm) (ca.) | Cys-Lager-Zahl |
| 25 | 47 | 16 | 0,124 | NN3005 |
| 25 | 47 | 16 | 0,121 | NN3005K |
| 30 | 55 | 19 | 0,199 | NN3006 |
| 30 | 55 | 19 | 0,193 | NN3006K |
| 35 | 62 | 20 | 0,242 | NN3007 |
| 35 | 62 | 20 | 0,235 | NN3007K |
| 40 | 68 | 21 | 0,312 | NN3008 |
| 40 | 68 | 21 | 0,303 | NN3008K |
| 45 | 75 | 23 | 0,405 | NN3009 |
| 45 | 75 | 23 | 0,393 | NN3009K |
| 50 | 80 | 23 | 0,433 | NN3010 |
| 50 | 80 | 23 | 0,419 | NN3010K |
| 55 | 90 | 26 | 0,651 | NN3011 |
| 55 | 90 | 26 | 0,631 | NN3011K |
| 60 | 95 | 26 | 0,704 | NN3012 |
| 60 | 95 | 26 | 0,683 | NN3012K |
| 65 | 100 | 26 | 0,758 | NN3013 |
| 65 | 100 | 26 | 0,735 | NN3013K |
| 70 | 110 | 30 | 1,04 | NN3014 |
| 70 | 110 | 30 | 1,01 | NN3014K |
| 75 | 115 | 30 | 1,14 | NN3015 |
| 75 | 115 | 30 | 1,11 | NN3015K |
| 80 | 125 | 34 | 1,52 | NN3016 |
| 80 | 125 | 34 | 1,47 | NN3016K |
| 85 | 130 | 34 | 1,61 | NN3017 |
| 85 | 130 | 34 | 1,56 | NN3017K |
| 90 | 140 | 37 | 2,07 | NN3018 |
| 90 | 140 | 37 | 2,01 | NN3018K |
| 95 | 145 | 37 | 2,17 | NN3019 |
| 95 | 145 | 37 | 2,1 | NN3019K |
| 100 | 150 | 37 | 2,26 | NN3020 |
| 100 | 150 | 37 | 2,19 | NN3020K |
| 105 | 160 | 41 | 2,89 | NN3021 |
| 105 | 160 | 41 | 2,8 | NN3021K |
| 110 | 170 | 45 | 3,69 | NN3022 |
| 110 | 170 | 45 | 3,56 | NN3022K |
| 120 | 180 | 46 | 3,98 | NN3024 |
| 120 | 180 | 46 | 3,83 | NN3024K |
| 130 | 200 | 52 | 5,92 | NN3026 |
| 130 | 200 | 52 | 5,71 | NN3026K |
| 140 | 210 | 53 | 6,44 | NN3028 |
| 140 | 210 | 53 | 6,21 | NN3028K |
| 150 | 225 | 56 | 7,81 | NN3030 |
| 150 | 225 | 56 | 7,53 | NN3030K |
